Осветление — Red, < 10 W, SMR-03V-B
Model
- Product Model
- MV-LRDS-H-105-0-R2
- Type
- MV-LRDS-H-105-0-R2
Performance
- Color
- Red
- Center illuminance
- ≥8000 Lux@WD=10 mm
- Best working distance
- 0 ~ 10 mm
- Irradiation angle
- 0°
- Wavelength
- 630 nm
Electrical feature
- Power
- 4.5 W
- Connector type
- SMR-03V-B
Mechanical
- Dimension
- Φ105 mm × 16 mm
- Outer dimension
- Φ105 mm
- Bore dimension
- Φ65 mm
- Emitting area length
- Φ75 mm
- LED rows
- 1
- Weight
- 190 g
- Cable length
- 1 m
- Humidity
- 20% RH to 90% RH (no condensation)
- Temperature
- Working temperature: 0 °C to 40 °C (32 °F to 104 °F) Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
- Diffuse plate included
- PMMA
Удължителни кабели, които пасват
Изчислено по конектора и протокола от каталога на производителя — не е негов официален списък. Питайте ни за потвърждение
MV-LW-H-001-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，1m
MV-LW-H-003-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，3m
MV-LW-H-005-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，5m
MV-LW-H-007-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，7m
MV-LW-H-010-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，10m
MV-LW-H-015-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，15m
MV-LW-H-020-1-S
Cable,SMR-03V-B to SMR-03V-BC，highflex，20m
MV-LW-H-030-1-S
