- Comply with IEEE802.3bm protocol standard, can meet 100G MPO fiber access
- QSFP28 optical module, with high density, low power consumption, high cost performance and other advantages
- Full metal shell packaging improves EMI performance, supports hot plugging
- Central wavelength 850 nm, MPO interface, meet the industrial visual field MPO fiber interface equipment access
MV-AC100G-QSFP28-850-MPO
HIKROBOT QSFP28 optical module
HIKROBOT QSFP28 optical module
Hikrobot provides high-quality cable products including power line, I/O control line, data transmission line to fulfill diverse application needs.
The cables’ length covers 0.5 m – 80 m to meet requirements in different scenarios. Even at the maximum length, the data transmission maintains high stability. Some cables also have motion performance, support the application scenes of moving drag chains.
Product Downloads:
| Model | Model | MV-AC100G-QSFP28-850-MPO |
| Name | QSFP28 optical module, MPO interface, 850nm | |
| Physical specifications | Central wavelength | 850 nm |
| Packaging | QSFP28 | |
| Interface type | MPO | |
| Transmission Rate | 103.1 Gbps | |
| Transmission Distance | 100 m | |
| Transmit Power | -8.4 ~ 2.4 dBm | |
| Receive Power | -10.3 ~ 2.4 dBm | |
| Other Information | Operating Temperature | 0°C ~ 70°C |
| Certification | RoHS | |
| Packaging | Independent packaging bag |
