MV-ACCL-SDR-MDR-HF-3m

HIKROBOT Data Cable, Flexible Camera Link, S2M, Straight, 3m, moveable

S2M, Camera Link, Flexible, Moveable, 3m

HIKROBOT Data Cable, Flexible Camera Link, S2M, Straight, 3m, moveable

Hikrobot provides high-quality cable products including power line, I/O control line, data transmission line to fulfill diverse application needs.
The cables’ length covers 0.5 m – 80 m to meet requirements in different scenarios. Even at the maximum length, the data transmission maintains high stability. Some cables also have motion performance, support the application scenes of moving drag chains.

Product Downloads:

Data Sheet

SKU: MV-ACCL-SDR-MDR-HF-3m Categories: , Tags: , , , ,
Compare
  • The Camera Link Flex Data Cable can be used for data transmission of Camera Link interface cameras, and is available in a variety of lengths.

ModelProduct ModelMV-ACCL-SDR-MDR-HF-3m
TypeCamera Link cable(SDR-MDR),high flex,3m
Physical specificationEnd A connectorSDR26
End B connectorMDR26
Cable diameter9.5 mm
Length3 m
Cable mechanicalUL20276
JacketPVC
Cable colorBlack
Connector modelmade in China
Connector durability500 cycles
Min. bending radius114 mm
Applicable scenarioDrag chain
Max. U-type bending cycles5 million times
Electrical specificationMax. voltage30 VDC
Additional informationWorking temperature-20°C~80°C
CertificationUL
PackagingIndividual package
