MV-ACCL-SDR-SDR-ST-5m

HIKROBOT Data Cable, Standard Camera Link, S2S, Straight, 5m, static

S2S, Camera Link, Static, 5m

HIKROBOT Data Cable, Standard Camera Link, S2S, Straight, 5m, static

Hikrobot provides high-quality cable products including power line, I/O control line, data transmission line to fulfill diverse application needs.
The cables’ length covers 0.5 m – 80 m to meet requirements in different scenarios. Even at the maximum length, the data transmission maintains high stability. Some cables also have motion performance, support the application scenes of moving drag chains.

Product Downloads:

Data Sheet

SKU: MV-ACCL-SDR-SDR-ST-5m Categories: , Tags: , , ,
Compare
  • The Camera Link Standard Data Cable can be used for data transmission of Camera Link interface cameras, and is available in a variety of lengths.

ModelProduct ModelMV-ACCL-SDR-SDR-ST-5m
TypeCamera Link cable(SDR-SDR),standard,5m
Physical specificationEnd A connectorSDR
End B connectorSDR
Cable diameter9.5 mm
Length5 m
Cable mechanical(28AWG*1P+AL)*11C+28AWG*2C+MY+AL+B, UL20276
JacketPVC
Cable colorBlack
Connector durability≥500 cycles
Min. bending radius114 mm
Applicable scenarioStatic scenes
Electrical specificationMax. voltage30 VDC
Additional informationWorking temperature-20°C~80°C
CertificationRoHS,UL
PackagingIndividual package
