- The Frame Grabber Standard I/O Cable (DB9F to Open) can be used for I/O signal wiring of the frame grabber with DB9M interface. The cable is equipped with shielding protection, and is available in a variety of lengths.
MV-ACP-DB9F-open-ST(EMC)-3m
HIKROBOT Power/IO Cable, Frame Grabber I/O Trigger Cable, DB9 to open, 3m
HIKROBOT Power/IO Cable, Frame Grabber I/O Trigger Cable, DB9 to open, 3m
Hikrobot provides high-quality cable products including power line, I/O control line, data transmission line to fulfill diverse application needs.
The cables’ length covers 0.5 m – 80 m to meet requirements in different scenarios. Even at the maximum length, the data transmission maintains high stability. Some cables also have motion performance, support the application scenes of moving drag chains.
Product Downloads:
| Model | Product Model | MV-ACP-DB9F-open-ST(EMC)-3m |
| Type | DB9 I/O cables | |
| Physical specification | End A connector | DB9F |
| End B connector | Open | |
| Cable diameter | 6.5 mm | |
| Length | 3 m | |
| Cable mechanical | UL20276 (26AWG*4P+26AWG*1C+AB) | |
| Jacket | PVC | |
| Cable color | Black | |
| Connector durability | >500 cycles | |
| Applicable scenario | Static scene | |
| Electrical specification | Max. voltage | 30 VDC |
| Additional information | Working temperature | -20℃ ~ 80℃ |
| Certification | RoHS，UL | |
| Packaging | Individual package |
