MV-ACP-H6p-open-ST-7m

HIKROBOT Power/IO Cable, Hirose 6pin, HR10A-7P-6S to Open, 7m

Power/IO, Hirose 6pin, HR10A-7P-6S to Open, 7m

HIKROBOT Power/IO Cable, Hirose 6pin, HR10A-7P-6S to Open, 7m

Hikrobot provides high-quality cable products including power line, I/O control line, data transmission line to fulfill diverse application needs.
The cables’ length covers 0.5 m – 80 m to meet requirements in different scenarios. Even at the maximum length, the data transmission maintains high stability. Some cables also have motion performance, support the application scenes of moving drag chains.

Product Downloads:

Data Sheet

Compare
  • The 6-pin P7 Standard Power&I/O Cable can be used to power the camera, I/O signal wiring, and is available in a variety of lengths.

ModelProduct ModelMV-ACP-H6p-open-ST-7m
TypeMV-ACP-H6p-open-ST-7m
Physical specificationEnd A connectorP7 6-pin,Femal
End B connectorOpen
Cable diameter5.0 mm
Length7 m
Cable mechanical26#×2P+26#×2C+AB
JacketPVC
Cable colorBlack
Connector modelmade in China
Connector durability≥ 750 cycles
Min. bending radius60 mm
Applicable scenarioStatic scene
Electrical specificationMax. voltage30 VDC
Additional informationWorking temperature-20°C~75°C
CertificationRoHS2.0,UL
PackagingIndividual package
