Бокс компютри — ARM: Raspberry Pi CM4, 2/4/8 GB, Based on CM4, 16/32 GB, Based on CM4, Raspberry Pi OS
Спецификации
- SKU
- CSRA4BOX
- Нетно тегло
- 900 g
- Форм-фактор
- Box
- Процесор
- ARM: Raspberry Pi CM4
- Оперативна памет
- 2/4/8 GB, Based on CM4
- Вградена памет (eMMC)
- 16/32 GB, Based on CM4
- Wi-Fi / Bluetooth
- CM4 dependable
- 4G / LTE
- Optional
- Zigbee
- Optional
- USB
- 1 x USB Type-C OTG; 2x USB 3.0 HOST
- CAN
- 1 x CAN-BUS
- RS232
- 2 x RS232 by default; up to 4 x RS232
- RS485
- 2 x RS485 by default that can be configured as 2 x RS232
- HDMI
- Yes
- GPIO
- Option 1: 4 x input, 4 x output from expander IC (optical isolated, DEFAULT). Option 2: 6 x CM4 CPU GPIO (conflict with option 1).
- LAN
- 2 x Giga LAN
- RTC
- High accuracy RTC with farad capacitor, can work 1 week after power off (default). High accuracy RTC with lithium coin battery, can work 3 years after power off (optional).
- I2C
- Not supported
- SATA II
- Not supported
- Зумер
- Onboard, driven by GPIO
- Аудио
- 3.5mm Audio In/Out Connector; Internal 2W Speaker
- Операционна система
- Raspberry Pi OS
- Ток
- 360mA (max) at 15V
- Входно захранване
- 9-30V DC
- Консумация
- 5.4W Max
- Работна температура
- 0°C to +60°C
- Начин на монтаж
- Rear, VESA
- Модул Raspberry Pi CM4
- CM4002000 ($57): 2GB DDR, no WiFi, or eMMC; CM4002016 ($79): No WiFi/BT+2GB DDR+16GB eMMC; CM4002032 ($100): No WiFi/BT+2GB DDR+32GB eMMC; CM4102016 ($100): WiFi+2GB DDR+16GB eMMC; CM4102032 ($105): WIFI+2GB DDR+32GB eMMC; CM4104016 ($137): WIFI+4GB DDR+16GB eMMC; CM4104032 ($142): WIFI+4GB DDR+32GB eMMC; CM4108032 ($216): WIFI+8GB DDR+32GB eMMC
