MV-ACCL-SDR-SDR-AOC-10m-Base

HIKROBOT Data Cable, Camera Link, AOC Fiber, SDR to SDR, Moveable, 10m, Base cable

Camera Link, AOC Fiber, SDR to SDR, Moveable, 10m, Base Cable

HIKROBOT Data Cable, Camera Link, AOC Fiber, SDR to SDR, Moveable, 10m, Base cable

Hikrobot provides high-quality cable products including power line, I/O control line, data transmission line to fulfill diverse application needs.
The cables’ length covers 0.5 m – 80 m to meet requirements in different scenarios. Even at the maximum length, the data transmission maintains high stability. Some cables also have motion performance, support the application scenes of moving drag chains.

Product Downloads:

Data Sheet

Compare
  • Camera Link fiber optic data cable can be used for data transmission between Camera Link interface cameras, and is available in a variety of lengths.

ModelModelMV-ACCL-SDR-SDR-AOC-10m-Base
NameCameralink AOC Fiber Optic Data Cable
Physical SpecificationsA-end InterfaceSDR26
B-end InterfaceSDR26 (board end, with Type A USB3.0 power connector)
Wire Harness Diameter5.6 ± 0.2 mm
Length10m
Cable StructureFiber*2C+(37/0.1)*1C+AL+B
Coating MaterialTPU
Cable ColorBlack
Connector Durability1000 Insertion and Removal Cycles
Minimum Bending RadiusWhen Installed: 100 mm
When Used: 67.2 mm
Allowable Tensile ForceWhen Installed: 300 N
When Used: 150 N
Allowable Crush ForceLong-term 200 N/100 mm
Short term 350 N/100 mm
Applicable scenariosDrag chain
Drag chain (U-shaped) sliding cycle number5 million times
Electrical specificationsPower supply5 V-400 mA
Other informationOperating temperature0°C ~ 70°C
PackagingIndividual packaging bag + paper box
