15.6" Панелни компютри и HMI — ARM: Raspberry Pi CM5, Based on CM5, Raspberry Pi OS, 1920 × 1080
Спецификации
- SKU
- CS19108RA5156A
- Нетно тегло
- 1600 g
- Форм-фактор
- All-In-One
- Процесор
- ARM: Raspberry Pi CM5
- Тактова честота на процесора
- Quad(4) Core Cortex-A76 at 2.4GHz
- Оперативна памет
- Based on CM5
- Вградена памет (eMMC)
- Based on CM5
- Постоянна памет
- 1 x TF card slot for boot
- PCIe
- M.2 M Key Connector, support NVMe SSD, support Hailo-8 M.2 M (Optional)
- Диагонал на екрана
- 15.6"
- Разделителна способност
- 1920*1080
- Яркост
- 350 NIT
- Сензорен екран
- Capacitive + Armored Glass
- USB
- 1 x Type-C USB (Slave); 2x USB 3.0 HOST
- GPIO
- 40-pin GPIO connector
- HDMI
- HDMI 2.0 connector, can be driven up to 4K 60FPS
- Зумер
- Onboard, driven by GPIO
- Ethernet
- 1 x Giga LAN
- RTC
- High accuracy RTC with farad capacitor, can work 1 week after power off (default). High accuracy RTC with lithium coin battery, can work 3 years after power off (optional).
- HAT конектор
- Standard Raspberry Pi 40-way HAT connector
- microSD слот
- For use only with CM5 Lite modules
- Wi-Fi / Bluetooth
- Depends on CM5
- 4G
- Not supported
- Аудио
- 3.5mm Audio In/Out Connector; Internal 2W Speaker
- Входно захранване
- 12V DC
- Консумация
- 12W
- Ток при 12 V
- 1A Max
- Работна температура
- 0℃~50℃
- Операционна система
- Raspberry Pi OS
- Модул Raspberry Pi CM5
- CM5102016 ($113): WiFi+2GB DDR+16GB eMMC; CM5104032 ($156): WiFi+4GB DDR+32GB; CM5108032 ($233): WiFi+8GB DDR+32GB
